M191H
Smallest High CMOS Color Mobile Camera
Feature

High Quality Color Waterproof Camera

Low-Illumination

Small& Compact Design

Color : Black, White and Silver

160° Wide Viewing Angle

Aluminum Die-casting Housing

Water-Proof Camera and Cable

  • Specification

    • No.

      DESCRIPTION

       MOBILE CAMERA

      REMARK

      1

      Pick-up Device

      1/3" CMOS Image Sensor



      2

      Pixels

      Total Pixel : 380K (762 X 504)

      Effective Pixel : 355K (728 X 488)



      3

      Resolution

      Max 560 TV - Lines



      4

      Current Consumption

      DC 12V, 40mA (Max)



      5

      Operating Voltage

      DC12V ( 5V~ 24V )



      6

      LENS

      160°: 120° (H) * 90° (V)



      7

      Video Out

      1.0V p-p composite, 75 ohm



      8

      Cable Length

      7.5 m cable



      9

      S/N Ratio

      More Than 48dB



      10

      Operating Temp

      -40 ~ 70



      11

      Min. illumination

      0.3 Lux



      12

      Color

      Black / White / Silver



      13

      Size

      28mm(D) x 34.2mm(L) x 26mm(H)



      14

      Weight

      95 g
